Specifications
- Horizontal run: manual 210 mm; E-motion 175 mm
- Motorized Vertical run: 500 mm; 500 mm
- C-Arm LATERAL Rotation: ± 140° (± 180° *); + 180°; – 90° (-180° manual)
- C-Arm ORBITAL Movement: 150° (105°, -45°); 150° (105°, -45°)
- WIG-WAG: ± 10°; ± 10°
- Useful space: 810 mm; 810 mm
- C-Arm Depth: 640 mm; 640 mm
- Min/ Max Height: 1455 / 1955 mm; 1455 / 1955 mm
- Min/Max Length: 2085/ 2295 mm; 2110/ 2285 mm
- Max Width: 800 mm; 800 mm
- I.D.: 1065 mm; 1065 mm
Operating modes and functionality
Operating modalities of (rtp) memory
- continuous fluoroscopy
- high dose pulsed fluoroscopy
- pulsed fluorography
- digital snapshot
- fluoroscopy ma : (range: 0,5-8 ma)
- radiography: 2 points technique (kv and mas)
- cine sequence: up to 25 fps. (included in basic configuration)
Software base funtion (live processing):
- display of patient data, hospital name, x-ray parameters on operator monitor
- recursive filter for noise reduction
- dynamic recursive filter for patient’s movement compensation
- edge enhancement spatial filter
- edge enhancement spatial filter
- horizontal and vertical image inversion
- digital zoom during fluoroscopy mode (new)
- metal detection in manual or automatic mode (new)
- continuous digital image rotation
- adjustable contrast and brightness
- adaptive gamma curve
- continuous fluoroscopy modality with lih (last image hold)
- low dose fluoroscopy
- timer function
- measurements: length, angles, with manual calibration system, text overlay
- anatomic program set up
- 80 anatomic programs in fluoroscope
Post-processing base features:
- last image hold (lih)
- last fluoroscopy run hold (lrh)
- horizontal/vertical image inversion
- digital image rotation
- greyscale image inversion
- adjustable contrast and brightness
- adjustable gamma curve (out)
- edge enhancement
- electronic shutters (rectangular and circular)
- electronic zoom roam from 1x to 5x
- electronic mobile lens
- mosaic overview
- patient’s selection for exams and images management
- patient’s exams transfer in the Dicom system
Applications:
- Electrophysiology studies
- Angiographic procedures
- Vascular surgery
- Endovascular applications
- Urology procedures
- Catheter procedures
- Neuroradiology
- General surgery
- Traumatology
- Orthopaedic
- Interventional radiology
Options
- DSA OPTION: Real time DSA with mask, Real time DSA with CO2 contrast liquid, Max opacity modality, Land marking, Road mapping, Mask selection for road mapping function, Virtual Road Mapping using fluorography image, Autoinjector delay selection, “CO2” contrast injection modality, Vascular tracing Function, Mask replace function, “Pixel shifting” function, Stenosimisure. In case the options are present all the relative functions are activated.
- Dicom function (option): Dicom verify, Dicom storage, Dicom worklist, Dicom media interchange, Dicom send, Dicom mpps, Dicom structured report, Dicom query/retrieve (q/r), Dicom print interface with Dicom film editor
- Thermal printer
- Patient radiation dose measuring device (DAP chamber)
- Laser localizer for centering the anatomical area to be examined on the I.I. side
- Remote wireless footswitch
